Crew : 4
Dimensions and weight ;
Total weight in combat order ;37 t
Overall length ; 8657 mm
Chassis length ;6243 mm
Overall width ;3270 mm
Overall height ; 2809 mm
Armament ;
Main gun ; 100-mm rifled gun (smoothbore in early versions)
Machine gun ;2 x 7.62-mm, 1 x 12.7-mm
Traverse range ;360 degrees
Combat load;
Main gun ;34 rounds
Machine gun ;3400 x 7.62-mm, 500 x 12.7-mm cartridges
Mobility
Engine power ;730 h.p.
Maximum road speed ;50 km/h
Autonomy on roads ;440 km
Maneuverability
Slope ;30°
Vertical step ;0.8 m
Ditch ;2.7 m
Ford unprepared ; 1.4 m
Selengkapnya...
Selasa, 28 April 2009
Medium Tank Type 69 (china)
Main Battle Tank EE-T1 "Osorio" (Brazil)
Entered service in 1988 -
Crew 4
Dimensions and weight
Total weight in combat order 41 t ~ 43 t
Overall length ? 10 100 mm
Chassis length 7 130 mm
Overall width 3 200 mm
Overall height 2 370 mm
Armament
Main gun 105-mm rifled gun L7A3 120-mm smoothbore gun
Machine guns 2 x 7.62-mm 1 x 7.62-mm, 1 x 12.7-mm
Traverse range 360 degrees
Combat load
Main gun 45 rounds 38 rounds
Machine guns 5 000 cartridges
Mobility
Engine power 1 040 h.p.
Maximum road speed 70 km/h
Autonomy on roads 500 km 550 km
Maneuverability
Slope 30°
Vertical step 1.15 m
Ditch 3 m
Ford (unprepared) 1.2 m
The EE-T1 "Osorio" Main Battle Tank was developed in the middle of 80-ties by "Engensa" - the largest Brazilian weapon developer. Companies technical politics is based on a wide usage of other companies providing military technologies scientific strides. Furthermore if some component production license price is too high, "Engensa" usually buys already produced and completes it's products with such, or offers job for specialists who took part designing one or another product. In this way "Engensa" resolves two main problems: it's production is at a high technology level and it's price is suitable even for a third world countries.
Hull and turret are differentially armored. Rear part is armored with a multi-layer armor which is made with included composite materials and is similar to British "Chobhem" armor. Frontal armor plates are placed with a high inclination level providing better defense.
"Osorio" armament is placed in three-seat turret. As well as EE-T1 is intended not only for Brazilian armored forces, but for export as well, it is produced with two armament variants. EE-T1 intended for Brazilian armored forces is armed with British L7A3 105-mm rifled gun, while export modification EE-T2 is fitted with French 120-mm smoothbore gun. It can be also completed with Soviet/Russian 2A46 125-mm smoothbore gun.
105-mm main gun combat load consists from 45 projectiles including armor-piercing and high-explosion with plastic explosives. Additional armament consists from 7.62-mm machine-gun, coaxially mounted with a main gun, one more 7.62-mm anti-aircraft machine gun is placed placed on the roof in front of gunner's hatch. "Osorio" can be completed with 12.7-mm anti-aircraft machine gun placed in front of the commander's hatch.
Main gun is stabilized in two planes. It's aiming and turret rotation devices are based on electricity. "Osorio" Main Battle Tank is fitted with Belgium commander's SCS-5 and gunner's LRS-5 sights. LRS-5 is combined periscope type sight. It combines optical sight with day and thermo vision night channels, also laser rangefinder and ballistic computer. Commander's sight differs from gunners in absence of laser rangefinder and ballistic computer. It is placed in commanders turret and connected with a main gun. Commander is able to aim and to fire independently from gunner. Tank's commander use 5 periscopes for 360 degree observation.
In 1987 "Engensa" finished EE-T1 export modification's - the EE-T2 Main Battle Tank's tests. The new main battle tank was intended only for export, mostly to the Near and Middle East countries. This modification was not used in Brazilian armored forces. The main difference is that the EE-T2 features 120-mm smoothbore gun instead of 105-mm placed on EE-T1 and improved fire control system.
EE-T2 "Osorio's" 120-mm gun ammunition load consists from 38 projectiles with two type rounds: armor-piercing and multifunction projectile (high-explosion fragmentation). It's fire controll system contains WS 580-10 commander panoramic sight and WS 580-19 gunners periscope sight. Sights are designed by French company "Sfim". Both sights are made with built-in laser rangefinders connected with ballistic computers. Sights viewing range has independent stabilization. One more "Philips" UA-9090 night vision panoramic thermal sight is mounted on the turret. It's view is projected on television screens, placed in front of gunner and commander. "Osorio" EE-T2 has a hit probability into moving target in 2 000 meter range from the first round in more than 80%. Such results were published by French specialists.
EE-T2 secondary armament consists from 7.62-mm coaxial and 12.7-mm anti-aircraft machine guns. Like the EE-T1 it is also fitted with a smoke grenade launchers, placed from both sides of the turret.
Both Main Battle Tanks have the same engine and transmission built in one module. Engines are German 12-cylinder MWM TBD 234 diesels with ZF LSG 3000 transmissions. Engine block is replaced in 30 minutes in field conditions.
Chassis includes 6 bearing and 3 supporting rolls from the each side. Tracks are similar to the "Leopard 2" Main Battle Tank's ones with removable rubber pads. Chassis suspension is hydro pneumatic. First, second and sixth bearing rolls are fitted with spring absorbers. Hull boards and chassis is covered with armored screens providing additional protection from cumulative rounds.
"Osorio" has a good speed and cross-country performance. It reaches 30 km/h in 10 seconds. Main Battle Tank manages 30ยบ slopes, 3 meter wide trenches, 1.15 meter vertical step. It fords 1.2 meter depth water obstacles without preparation.
The Main battle tank is completed with an automatic fire-extinguishing system in combat and engine-transmission compartments. "Osorio" can be additionally fitted with Nuclear Biological Chemical protection system. This system includes air filter and individual masks for crew members, providing cleaned air. There is also ability to place special device signalizing when main battle tank is lightened by a laser beam. It is also fitted with all necessary radio equipment and crew communication devices.
Later on the "Osorio" Main Battle Tank chassis there were based such armored vehicles:
- Self-propelled howitzer fitted with GHN-45 155-mm howitzer;
- Anti-aircraft defense vehicle with coaxial "Oerlicon" automatic guns;
- Armored engineering vehicle;
- Tank - bridge-layer.
There is no information about the "Osorio" EE-T2 serial production, however countries such as Saudi Arabia showed interest to obtain it for their armored forces. Brazilian requirements in EE-T1 is approximately 300 main battle tanks. Selengkapnya...
Minggu, 26 April 2009
SINGAPOUR army military equipment vehicle( Armoured vehicle)
Singapour_army_Rapier_Mk2_001
Primus_Howitzer_Singapour
Primus_howitzer_155mm_Singapour
M113A2_Igla_missile_Singapour
Leopard2_A4_Singapore
Cadillac_Gage_V-200_RBS-70_Singapour
Bronco_Singapour_army
Bronco_mortar_Carrier_singapour
Bronco_ATTC_mortar_carrier_120mm_Singapour
Bionix_AVLB_Singapore
Bionix_45-50_apc_Singapour
Bionix_25_Singapour
AMX-13-SM1
AMX-13S1_Singapour
Selengkapnya...
MALAYSIAN army military armoured
Malaysian 6x6 light wheeled vehicle
PT-91M main battle tank
Astros II (Artillery Saturation Rocket System)
AIFV Armoured infantry fighting vehicle
Selengkapnya...
MRAP II Caiman in action.
Based on the ultra-reliable Family of Medium Tactical Vehicles (FMTV) platform and the combat-proven Low Signature Armored Cab (LSAC), the Caiman incorporates the demonstrated performance of these components into a highly survivable and sustainable MRAP vehicle designed to defeat current and emerging threats on today’s battlefield. Leveraging its high-volume tactical vehicle production facilities, BAE Systems is currently producing 40 Caiman vehicles per month and ramping up to 300 vehicles per month by January 2008.
BAE Systems is currently producing 1,154 Category I and 16 Category II vehicles to fulfill a $518.5 million MRAP contract, with the U.S. Marine Corps.
The high level of parts commonality with the FMTV ensures that the Caiman will maintain the same levels of readiness, mobility, serviceability, and worldwide support as the more than 36,000 FMTVs already fielded.
Caiman features: 10-man crew capacity
Armoring enhancement capable
Accepts all types of manned and remote weapons stations
85 percent parts commonality with standard FMTV models
Full-time all wheel drive
Fully automatic transmission
Electronic Central Tire Inflation System (CTIS)
Anti-lock Braking System (ABS)
Class V Interactive Electronic Technical Manuals (IETM)
Sabtu, 25 April 2009
Assault Rifle SS2
Assault Rifle SS2 SS2 is a new generation of assault rifle having caliber 5.56 x 45 mm and barrel twist 7?. It has lightweight, reliability, and high accuracy by using foldable butt to make it flexible for suitable necessities. This rifle is compatible with mechanical or optical sight as well as suitable with several accessories such as silencer, bayonet, grenade launchers, etc. It has also been developed into types of long and short barrels that can be used with mechanical or optical sight to meet with its operation in the battlefield.
Specifications | |||
Pindad Code | SS2-V1 | SS2-V2 | SS2-V4 |
|---|---|---|---|
NSN | - | - | - |
Calibre | 5.56 X 45 mm | 5.56 X 45 mm | 5.56 X 45 mm |
Barrel Length | 460 | 403 | 460 |
Overall Length | |||
Butt Extended | 990 | 920 | 990 |
But Folded | 740 | 670 | 740 |
Weight | |||
With Empty Magazine | 3.4 kg | 3.2 kg | 4.2 kg |
Cyclic Rate of Fire | 675 - 725 rpm | 675 - 725 rpm | 675 - 725 rpm |
Mode Firing | Single, Full Auto, Safe | Single, Full Auto, Safe | Single, Full Auto, Safe |
Sight | Mechanical Sight | Mechanical Sight | Optical Sight |
Max Effective Range | 500 m | 400 m | 600 m |
Finishing | Black / Gray | Black / Gray | Black / Gray |
Pindad Panser
| Type | Armoured personnel carrier |
|---|---|
| Place of origin |  Indonesia |
| Service history | |
| Used by | Indonesia |
| Production history | |
| Designer | PT Pindad |
| Designed | 2006 |
| Manufacturer | PT Pindad |
| Produced | 2006 |
| Number built | 150 |
| Specifications | |
| Weight | 11 tonnes, 14 tons (combat) |
| Length | 6000 mm |
| Width | 2500 mm |
| Height | 2500 mm / 2900 mm (FSV variant) |
| Crew | 3 + 10 passengers |
| | |
| Armor | Monocoque Armoured, STANAG 4569 level 3 |
| Primary armament | 12.7 mm MG, CIS 40 AGL |
| Secondary armament | 6 x 60mm smoke grenade launcher |
| Engine | Renault MIDR 062045 inline 6 cylinder turbo-charged diesel,[1] Behr cooling pack 320Hp, 2500 Rpm |
| Power/weight | 22,85 HP/tons |
| Transmission | Automatic, ZF S6HP502, 6 forward, 1 reverse |
| Suspension | Independent suspension, torsion bar |
| Ground clearance | 40 cm |
| Fuel capacity | 200 litres |
| Operational range | 600 km |
| Speed | 90 km/h |
The Casspir is a landmine-protected personnel carrier (APC) that has been in use in South Africa for over 20 years. It is a four wheeled armoured vehicle, used for transport of troops. It can hold a crew of two, plus 12 additional soldiers and associated gear. The Casspir was unique in design when launched, providing for passive mine defence. The main body of the vehicle is V-shaped and raised above the ground, so that if a mine is detonated, the explosion is less likely to damage the crew compartment and kill the occupants. The cross-section of the hull is V-shaped, directing the force of the explosion outwards, further protecting the occupants. The vehicle is also armoured for added mine safety, as well as protection from small arms fire. The Casspir was the inspiration and prototype for the US Marines MRAP project.
Selengkapnya...
Marines with Company D, Light Armored Reconnaissance, Battalion Landing Team 3/1, 11th Marine Expeditionary Unit (MEU) (Special Operations Capable), focus down range during recent live-fire training. With the aide of their Light Armored Vehicle Two Five (LAV-25), the Marines can undertake a number of missions, to include facilitating reconnaissance, artillery direction and ‘hit and run missions.’ Each LAV-25 is equipped with a 25mm chain gun and two M-240E1 machine guns, enabling the Marine gunners to accurately fire on targets while moving at speeds of up to 10 mph due to the vehicle's stabilization system. U.S. Marine Corps photo.
Selengkapnya...
LAV-APC
| Type | APC |
|---|---|
| Place of origin |  Switzerland Canada |
| Specifications | |
| Weight | 12.80 t (14.10 sh tn) |
| Length | 6.39 m (20.96 ft) |
| Width | 2.50 m (8.20 ft) |
| Height | 2.69 m (8.83 ft) |
| Crew | 3+6 |
| | |
| Primary armament | M242 Bushmaster 25 mm chain gun |
| Secondary armament | Two M240 7.62 mm machine guns, one mounted coaxially and one pintle mounted on the roof |
| Engine | Detroit Diesel 6V53T 275 hp (205 kW) |
| Power/weight | 19.5 hp/sh tn (16.0 kW/t) |
| Transmission | Allison MT653 |
| Suspension | 8×8 wheeled |
| Operational range | 660 km (410 mi) |
| Speed | 100 km/h (62 mph) |
Private Ryan VanHorlick, C-6 gunner for 8th Platoon, C Coy., 3rd PPCLI, grins and lets his weapon lay suppression fire during an urban assault at the 13th MEU's MAGTFEX. The exercise is part of the MEU's pre-deployment work-ups for the WESTPAC-05 deployment.
Selengkapnya...
Utilitiesman 3rd Class Eduardo Riveragonzalez assigned to Naval Mobile Construction Battalion Seventy Four (NMCB-74), fires a 7.62mm caliber M240B machine gun down range during weapons qualifications
Selengkapnya...
A Marine aboard an LAV-25 light armored vehicle holds onto the L7A2 machine gun mounted on the vehicle's turret while on patrol in the city. Marines are in Zakhu as part of Operation Provide Comfort, multinational effort to aid Kurdish refugees in southern Turkey and northern Iraq.
Selengkapnya...
The Maschinengewehr 34, or MG34, was a German machine gun that was first produced and accepted for service in 1934, and first issued to units in 1935. It was an air-cooled machine gun firing 7.92x57mm Mauser rounds and had similar performance to other medium machine guns.
However, it was also designed to perform both as a light machine gun and also in heavier roles, in an early example of a general purpose machine gun. In the light role, it was intended to be equipped with a bipod and 50-round belt contained in a drum-shaped ammo basket, which attached to the receiver. In the heavier role it was mounted on a larger tripod and was belt-fed. In practice the infantry usually just belt-fed the bipod version, resulting in it functioning as a classic medium support weapon.
Selengkapnya...PKM
| Type | General purpose machine gun |
|---|---|
| Place of origin |  Soviet Union |
| Service history | |
| In service | 1965-present |
| Used by | See Users |
| Production history | |
| Designer | Mikhail Kalashnikov |
| Designed | Ca early 1960s |
| Number built | over 1,000,000 |
| Variants | PK, PKS, PKT, PKM, PKMS, PKP |
| Specifications | |
| Weight | PK: 9 kg (19.84 lb) (gun + integral bipod) + 7.7 kg (16.98 lb) (tripod). PKM: 7.5 kg (16.53 lb) (gun + integral bipod) + 4.5 kg (9.92 lb) (tripod). PKT (tank): 10.5 kg (23.15 lb) |
| Length | PK - 1,173 mm (46.2 in) PKM - 1,160 mm (45.7 in) PKT - 1,098 mm (43.2 in) |
| Barrel length | PK - 658 mm (25.9 in) PKM - 645 mm (25.4 in) PKT - 772 mm (30.4 in) |
| | |
| Cartridge | 7.62x54mmR |
| Action | Gas-Operated, open bolt |
| Rate of fire | PK, PKM ,PKP : 650 round/min. PKT: 800 round/min |
| Muzzle velocity | PK, PKM, PKP: 825 m/s |
| Effective range | 100—1,100 m sight adjustments [1] |
| Feed system | Belts in 100/200/250 round boxes |
| Sights | Open sights |
RPK-74
| Tipe | Senapan mesin ringan |
|---|---|
| Negara asal | Uni Soviet |
| Sejarah pemakaian | |
| Digunakan | 1961–sekarang |
| Pemakai | Rusia, Polandia, Tiongkok, Romania, Yugoslavia, Jerman Timur |
| Perang | Perang Vietnam, Perang Afganistan |
| Sejarah produksi | |
| Tahun | 1961 |
| Diproduksi | 1961–1978 |
| Varian | RPK, RPKS, RPKSN |
| Spesifikasi | |
| Berat | 5 kg |
| Panjang | 1.040 mm |
| Panjang laras | 591 mm |
| | |
| Peluru | 7.62 x 39 mm M43 |
| Kaliber | 7.62 mm |
| Mekanisme | Operasi gas, bolt berputar |
| Kec. tembak | 600 butir/menit |
| Kec. peluru | 745 m/s |
| Pengisian | Magazen box 30 atau 40 butir Magazen drum 75 atau 100 butir |
